Product Summary

The STK403-120 is an AMP schematic diagram.

Parametrics

STK403-120 absolute maximum ratings: (1)maximum power supply voltage 0: ±65V; (2)maximum power supply voltage: ±57V; (3)maximum operating current: 0.6mA; (4)junction temperature: 150℃; (5)operating substrate temperature: 125℃; (6)storage temperature: -30 to 125℃.

Features

STK403-120 features: (1)case outline 15pins; (2)function: 2 channels AF power amplifier; (3)application: 80W audio use; (4)maximum ratings.

Diagrams

STK403-120 block diagram
